Dimension Table
Dimensions for PTFE Coated Stainless Steel Hex Socket Button Head Screw in all available sizes are shown according to the product drawing above.
Couldn't load pickup availability
Need Help?
Our team are always happy to help!
Live Chat: Available from the bottom right of your screen.
Email: sales@highperformancepolymer.com
Phone: +44(0)1865 684080
Material: PTFE Coated
Measurement System: Metric
Drive Type: Hex Socket
Blue
260°C
UL94 V0
PTFE Coated Stainless Steel Hex Socket Button Head Screw conform to the following Standards/Norms:
ISO 7380
PTFE Coated Stainless Steel Hex Socket Button Head Screws, available in sizes ranging from M5 to M12 with lengths between 8mm and 120mm. These high-performance screws are crafted from premium stainless steel and feature a PTFE (Polytetrafluoroethylene) coating that offers outstanding corrosion resistance, reduced friction, and enhanced wear protection. The PTFE coating provides a sleek, non-stick finish, making these screws ideal for applications in chemical processing, marine environments, and other demanding conditions where durability and reliability are paramount. Perfect for industrial and specialized applications, these screws deliver superior performance and longevity.
Metric Size – M5, M6, M8, M10, M12
Length (mm) – 8, 10, 12, 14, 16, 18, 20, 22, 25, 30, 35, 40, 40, 50, 60, 70, 80, 90, 100, 110, 120
PTFE (Polytetrafluoroethylene) coated stainless steel combines the desirable properties of both materials to create a versatile and highly functional composite. Here's a brief overview of its properties:
Corrosion Resistance: Stainless steel inherently resists corrosion due to its chromium content, while PTFE adds an additional layer of protection, making the material highly resistant to rust, chemicals, and environmental degradation.
Low Friction: PTFE is known for its low coefficient of friction, providing smooth and easy movement. When coated onto stainless steel, it reduces friction between surfaces, preventing wear and enhancing durability.
Chemical Inertness: PTFE is chemically inert and resistant to a wide range of chemicals. When applied to stainless steel, it enhances the material's resistance to acids, bases, solvents, and corrosive substances.
Temperature Stability: PTFE exhibits exceptional thermal stability, maintaining its properties over a wide range of temperatures (-200°C to +260°C). When combined with stainless steel, it enhances the material's ability to withstand extreme temperatures without losing its integrity.
Non-Stick Properties: PTFE has excellent non-stick properties, preventing adhesion of substances to its surface. When coated onto stainless steel, it creates a non-stick surface that is easy to clean and maintain.
Electrical Insulation: PTFE is a good electrical insulator, providing resistance to electricity and preventing electrical conductivity. When applied to stainless steel, it enhances the material's electrical insulation properties.
Biocompatibility: PTFE is biocompatible and inert to biological tissues, making it suitable for medical and pharmaceutical applications. When coated onto stainless steel, it enhances the material's biocompatibility, reducing the risk of adverse reactions in biological systems.
What are Hex socket button head screws?
Hex socket button head screws are fasteners characterised by a cylindrical head with a low-profile, rounded top and a recessed hexagonal socket (Allen socket) in the centre. They feature machine threads along the shaft and are tightened or loosened using a hex key (Allen key) inserted into the socket. These screws are designed to sit flush with the surface when installed, providing a neat and finished appearance. They are commonly used in various industries and applications where a clean, low-profile fastening solution is required.
The PTFE Coated data sheet is available as a PDF to download below.
Return components within 90 days for a full refund. Please see returns terms and conditions for further information.
Size | Head Diameter (mm) | Head Height (mm) | Socket Width (mm) |
M3 | 5.7 | 1.65 | 2.08 |
M4 | 7.6 | 2.2 | 2.58 |
M5 | 9.5 | 2.75 | 3.08 |
M6 | 10.5 | 3.3 | 4.095 |
M8 | 14 | 4.4 | 5.14 |
M10 | 17.50 | 5.5 | 6.14 |
M12 | 21 | 6.6 | 8.175 |
Dimensions for PTFE Coated Stainless Steel Hex Socket Button Head Screw in all available sizes are shown according to the product drawing above.
Follow the link below to view our PTFE Coated data sheet. This includes properties such as mechanical, electrical, thermal and chemical resistance.
